N215EM Cylindrical Roller Bearing – High-Load, Precision, Low Friction
Basic Info
| Inner Diameter | 75 mm |
|---|---|
| Outer Diameter | 130 mm |
| Width | 25 mm |
Introduction
Cylindrical roller bearing NUP215EM, made of bearing steel, radial load type, single row, open seal, precision grades P0–P2. Suitable for high-speed and heavy-load applications with OEM/ODM service available.
Apple Shopping Event
Hurry and get discounts on all Apple devices up to 20%
Sale_coupon_15
-
Pick up from the Woodmart Store
To pick up today
Free
-
Courier delivery
Our courier will deliver to the specified address
2-3 Days
Free
-
DHL Courier delivery
DHL courier will deliver to the specified address
2-3 Days
Free
-
Warranty 1 year
-
Free 30-Day returns
Payment Methods:
Description
SKF-Grade Cylindrical Roller Bearing NUP215EM – High-Precision Radial Support
| Description | Key Specification |
|---|---|
| Core Design | NUP-type (fixed double-flanged outer ring + loose inner ring with rib) |
| Dimensions (mm) | 75 × 130 × 25 — optimized for compact high-load radial applications |
| Material & Hardness | High-carbon chromium bearing steel (GCr15), hardened to HRC 60–64 |
| Precision Rating | P0 (standard) to P2 (ultra-precision) — fully interchangeable with SKF NUP215 series |
| Load Capacity | Dynamic C: 142 kN / Static Co: 132 kN — 12% higher than generic equivalents |
| Operating Temp. | −30°C to +120°C (with standard grease); up to +150°C with high-temp lubrication |
| Sealing & Lubrication | Open design — compatible with oil, grease, or solid-lubricant systems |
| Application Scope | Electric motors, gearboxes, pumps, compressors, wind turbine gearboxes, industrial drives |
| Quality Assurance | 100% dimensional inspection, noise testing (≤28 dB at 1800 rpm), ISO 9001 & IATF 16949 certified |
| Why Choose Us? | BDL OEM partner for SKF-compatible interchange; 2-year warranty; batch traceability; RoHS/REACH compliant |
FAQ: Q: Is NUP215EM suitable for axial displacement? A: Yes — the NUP configuration allows limited axial float on one side while fixing axially on the other. Q: Can it replace SKF NUP215? A: Fully dimensionally and performance-interchangeable. Q: What’s the max speed? A: 5,200 rpm (oil-lubricated, P0 grade). Q: Do you supply matched sets? A: Yes — pre-matched pairs/triples for tandem mounting available upon request.
Ready to source precision-engineered cylindrical roller bearings with SKF-level reliability? Send your inquiry now — get technical support, CAD models, and bulk pricing within 2 hours.
