Thrust Ball Bearing
ISO 9001 Certified
TS 16949
Genuine SKF
Need Technical Advice?
Reply within 12 hours · 15+ certified engineers on call
Thrust Ball Bearing
High-Quality Thrust Ball Bearings 53208–53211, Precision Steel
Basic Info.
| Inner Diameter | 55 mm |
| Outer Diameter | 90 mm |
| Thickness | 27.3 mm |
| Lubrication | Grease or Oil |
| Precision Rating | P0, P6, P5, P4, P2 |
| Load Direction | Thrust Bearing |
Introduction
High-precision thrust bearing made of bearing steel, suitable for high-load axial applications. Features grease or oil lubrication, multiple precision grades (P0–P2), and complies with ISO9001:2008. Ready for immediate shipment from stock.7
Day Prototype
vs. 8-12 wks standard
50+
Countries Served
Global logistics network
12h
Quote Response
Expert engineers on call
Typical Applications
Wind Power
Mining
Steel & Metallurgy
Automotive / EV
Rail Transit
Precision Machinery
Genuine SKF Bearings
NDA Protected
Free Sample for Orders > $50K
Global Shipping
Product Details
Key Specifications & Advantages of BDL Thrust Ball Bearing 53211
| Description | Core Value |
|---|---|
| Model: 53211 (part of 53208–53211 series) | Standardized interchangeability with SKF 53211 — ideal for global OEM replacements |
| Dimensions: 55×90×27.3 mm | Precise metric sizing ensures drop-in fit in industrial thrust applications |
| Material: High-carbon bearing steel (GCr15 equivalent) | Superior hardness & fatigue resistance vs. generic carbon steel |
| Precision Grades: P0/P6/P5/P4/P2 | Meets or exceeds ISO ABEC standards — P2 available for high-speed precision systems |
| Vibration Classes: Z1V1 to Z3V3 | Ultra-low noise operation — critical for HVAC, medical, and automation equipment |
| Lubrication: Grease or oil compatible | Flexible maintenance — pre-greased options available for sealed applications |
| Certification: ISO 9001:2008 certified | Consistent quality control — traceable batch testing & documentation |
| Design: Non-aligning, separated, single-row thrust bearing | Optimized axial load capacity (dynamic Ca: 98 kN) with easy assembly |
| Origin & Compliance: Made in China | HS Code 8482102000 | Fully customs-compliant; supports CE/UKCA-marked end products |
| OEM/ODM Support + In Stock | Fast lead times & custom branding — no MOQ for standard models |
Engineered for demanding axial-load environments — from hydraulic pumps and crane turntables to machine tool spindles and automotive steering systems. Unlike budget alternatives, BDL 53211 features strict dimensional tolerances, micro-finished raceways, and controlled internal clearance — delivering 20–30% longer service life under identical loads (based on L10 life testing). All units undergo 100% vibration screening and dynamic load verification. Have a special requirement? Contact us now for technical support, sample requests, or volume pricing.
Product Summary
- Product Name
- High-Quality Thrust Ball Bearings 53208–53211, Precision Steel
- Category
- Thrust Ball Bearing
- Brand
- SKF
- Certification
- ISO 9001 · TS 16949
- Lead Time
- 7 Working Days
Get a Custom Quote
Our engineers will respond within 12 hours with a tailored solution.
Request QuoteGeneral Specifications
| Bearing Type | Thrust Ball Bearing |
| Brand | SKF |
| Quality Standard | ISO 9001 / TS 16949 |
| Precision Grade | P0 / P5 / P6 (custom) |
| Material | Chrome Steel / Stainless |
| Cage Material | Steel / Brass / Polyamide |
| Lubrication | Grease / Oil (specify) |
| Operating Temp. | -40°C to +200°C |
| Min. Order Qty | 1 pc (samples available) |
| Prototype Lead Time | 7 Working Days |
Performance Parameters
| Load Capacity | Contact for C0/Cr values |
| Speed Rating | Contact for ndm limit |
| Vibration Level | Z1 / Z2 / Z3 (custom) |
| Noise Level | V1 / V2 / V3 (custom) |
| Fatigue Life | L10h per ISO 281 |
| Sealing Options | Open / Z / 2Z / RS / 2RS |
Custom Specifications Available
Our engineering team can modify bearing dimensions, materials, seals, and clearances to meet your specific operating requirements. Submit your drawing or spec sheet for a tailored proposal.
Wind Power
Main shaft bearings, gearbox bearings, and generator bearings for onshore and offshore wind turbines.
Mining & Quarrying
Heavy-duty bearings for crushers, conveyors, and rotary equipment in extreme dust and shock-load environments.
Steel & Metallurgy
High-temperature bearings for rolling mills, continuous casting, and furnace applications.
Automotive / EV
Wheel hub bearings, transmission bearings, and e-motor bearings for passenger and commercial vehicles.
Rail Transit
Axle box bearings, traction motor bearings, and gearbox bearings meeting EN/UIC railway standards.
Precision Machinery
High-precision spindle bearings, angular contact bearings, and super-precision bearings for CNC and robotics.
Application Design
EngineeringOur engineers analyze your operating conditions -- load, speed, temperature, environment -- and select or design the optimal bearing solution to maximize service life and reduce total cost of ownership.
Custom Modification
7-Day TurnaroundNeed non-standard dimensions, special materials, or modified clearances? We can modify standard SKF bearings or manufacture fully custom solutions with a 7-day prototype turnaround.
Failure Analysis
DiagnosticsWhen bearings fail prematurely, our team conducts root-cause analysis using advanced diagnostic tools to identify the failure mode and recommend corrective action.
Predictive Maintenance
Up to 40% Less DowntimeWe deploy vibration monitoring, thermal imaging, and oil analysis programs that detect bearing deterioration early -- reducing unplanned downtime by up to 40%.
On-site Installation
Global CoverageProper installation is critical to bearing performance. Our certified technicians provide on-site installation support, alignment verification, and operator training worldwide.
Lifecycle Support
Enterprise SLAFrom initial selection through end-of-life, our dedicated account managers provide scheduled maintenance plans, re-lubrication programs, and replacement forecasting for enterprise clients.
Why SKF China
The engineering partner advantage
7 Days
Prototype Lead Time
vs. 8-12 weeks via standard channels
15+
Certified Engineers
SKF-certified, on-call for your project
50+
Countries Delivered
Reliable global logistics network
Request a Quote
Get a custom quote for
High-Quality Thrust Ball Bearings 53208–53211, Precision Steel
NDA protected · Free samples for orders > $50K · Reply within 12 hours
